CLK-DIV (Clock Divider Module)

주요 스펙

Frequency (input)
  • :1 GHz to 17 GHz
Frequency (output)
  • :3.8 MHz to 17 GHz
Amplitude
  • :500 mV to 900 mV
Clock Jitter rms
  • :0.8 ps
Clock duty cycle
  • :45 ~55 %
 - Operating input frequency 1 GHz to 17 GHz
 - Output amplitude 0 dBm
 - Differential clock output
 - Output can be driven single ended as well; unused outputs should be terminated
 - Small size : 25.4 mm (1") width
 - Operating input frequency 1 GHz to 17 GHz
 - Output amplitude 0 dBm
 - Differential clock output
 - Output can be driven single ended as well; unused outputs should be terminated
 - Small size : 25.4 mm (1") width
