CLK6-2 (Clock source module)

주요 스펙

Data Rate
  • :50 MHz to 900 MHz
Output level (싱글)
  • :550 mVpp to 950 mVpp
Output level (차동)
  • :1100 mVpp to 1900 mVpp
Phase jitter RMS
  • :0.26 to 0.27 ps
Phase noise
  • :-97 dBc/Hz
Clock source 1/16
Clk6-2 is a clock source module that plugs into the XBERT and ParalleX? Chassis. The clock works over a continous range of 50 MHz to 900 MHz. Functionally it is not bound to the EBERT modules hence it can be used for driving any other devices, too.  For easier operation it has six predefined clock frequencies typically used in telecom and datacom.

Characteristics
 - Selectable data rates:
   531MHz = (1/16) * 8.5G
   622MHz = (1/16) * 9.9G
   644MHz = (1/16) * 10.3G
   657MHz = (1/16 )* 10.5G
   666MHz = (1/16) * 10.7G
   693MHz = (1/16) * 11.1G
   707MHz = (1/16) * 11.3G
 - Additionally user definable frequency in the range 50MHz ? 900MHz
 - Differential Output

Applications
 - OC-192 SONET / SDH64
 - OC-192 SONET Over FEC
 - 10Gbps Fibre Channel
 - ITU G.709
 - 10Gbps Ethernet, IEEE 802.3ae
 - 10 Gigabit Ethernet Over ITU G.709
Characteristics
 - Selectable data rates:
   531MHz = (1/16) * 8.5G
   622MHz = (1/16) * 9.9G
   644MHz = (1/16) * 10.3G
   657MHz = (1/16 )* 10.5G
   666MHz = (1/16) * 10.7G
   693MHz = (1/16) * 11.1G
   707MHz = (1/16) * 11.3G
 - Additionally user definable frequency in the range 50MHz ? 900MHz
 - Differential Output

Applications
 - OC-192 SONET / SDH64
 - OC-192 SONET Over FEC
 - 10Gbps Fibre Channel
 - ITU G.709
 - 10Gbps Ethernet, IEEE 802.3ae
 - 10 Gigabit Ethernet Over ITU G.709
