DEP-3 (De-Emphasis Module)

주요 스펙

Data Rate
  • :2 Gbps to14.4 Gbps
Output DATA V
  • :100 mVpp to 900 mVpp
Output Clock V
  • :100 mVpp to 500 mVpp
De-Emphasis Range
  • :0 to 10 dB (0.5dB)
Input Voltage
  • :100 mVpp to 500 mVpp
- Compensate losses across FR4 PCB or cable by signal pre-distorion
- Input data rate 2 Gbps to 14.4 Gbps
- Differential as well as single ended output operation
- Selectable De-Emphasis (0-10dB)
- Adjustable Crossing (40% - 60%)
- Small size : 25.4 mm (1") width
- Compensate losses across FR4 PCB or cable by signal pre-distorion
- Input data rate 2 Gbps to 14.4 Gbps
- Differential as well as single ended output operation
- Selectable De-Emphasis (0-10dB)
- Adjustable Crossing (40% - 60%)
- Small size : 25.4 mm (1") width
